OEM: Available
Standard: ASME, ASTM, EN, UNS, GB, DIN, JIS
Product Certification: ISO, CE, RoHS
Payment Terms: T/T, L/C, PayPal, Western Union
Specification | |||||||||||
GB/T | UNS | AISI/ASTM | Trademark | W.Nr | |||||||
NS143 | N08020 | Alloy20Cb-3 | Carpenter20Cb3 | 2.4660 | |||||||
Chemical Composition: |
| ||||||||||
Grade | % | Ni | Cr | Mo | C | Fe | |||||
Alloy 20 | Min | 32 | 19 | 2 | - | Rest | |||||
Max | 38 | 21 | 3 | 0.07 |
| ||||||
| Mn | Si | S | Cu | P |
| |||||
| - | - | - | 3 |
|
| |||||
| 2 | 1 | 0.03 | 4 | 0.03 |
| |||||
Physical Performance: | |||||||||||
Density | 8.08 g/cm3 | ||||||||||
Melting point | 1357-1430 | ||||||||||
Heat Treatment | T*S | Y*S | El | Hardness | |||||||
Rm N/mm2 | RP0.2N/mm2 | % | HB | ||||||||
Solution | 600 | 320 | 35 | - | |||||||
·Chemical and allied industries
·Food and dye production
·Heat exchangers
·Explosives
·Tanks
·Valves
·Pickling racks
·Manufacture of synthetic rubber and plastics
·Pharmaceuticals
·SO2 scrubbers and other severe environments
1. Standard Exporting package.
2. Original package or neutral package.
3. According to clients ' needs.
4. Shipped in10-35 days after payment.
Price
Q: How can I get the Alloy 20 price?
A: You can contact us through sending inquiry, calling, or get details price list by E-mail.
Delivery
Q: How long is Alloy 20 delivery time?
A: It depends on quantity. Usually, 10-35 working days.
Sample
Q: Can I get Alloy 20 sample to check the quality?
A: Of course. We can supply sample, and free for some small value products.
OEM
Q: Do you provide Alloy 20 OEM service?
A: Yes, we do. Customized design is available.
Payment
Q: What is your payment term?
A: L/C, T/T, PayPal, Western Union, etc.
Certificate
Q: What certificate do your products have?
A: CE, ISO9001, RoHS, SGS, etc.
Alloy 20 is a nickel–chromium–molybdenum alloy developed for applications involving sulfuric acid. Its corrosion resistance also finds other uses in the chemical, food, pharmaceutical, power generation, and plastics industries.
Alloy 20 (UNS N08020) is an austenitic, nickel-iron-chromium based super alloy with additions of Copper and Molybdenum which provide resistance to hostile environments, pitting, and crevice corrosion. It is also stabilized with Columbium to minimize carbide precipitation during welding. Alloy 20 appears to fall between both the stainless and nickel categories as it contains characteristics of both. It was designed for maximum resistance to acid attack and demonstrates superior resistance to stress-corrosion cracking in boiling 20% to 40% sulfuric acid, and also has excellent general corrosion resistance to sulfuric acid and to chloride stress corrosion cracking. Alloy 20 has good mechanical properties at both ambient and elevated temperatures, up to approximately.
