022CR17NI12MO2 Stainless Steel

Characteristics: High temperature strength
Standard: ASME, ASTM, EN, UNS, GB, DIN, JIS
Certification: ISO, CE, ROHS
Payment Terms: T/T, L/C, Paypal, Western Union

Send Inquiry

Product Details

022CR17NI12MO2 stainless  steel, also known as titanium steel, 316L quality steel.
 Add Mo(2~3%),  excellent corrosion resistance, high temperature creep strength.



022CR17NI14MO2 Stainless Steel Chemical Composition

C

Si

Mn

S

P

Cr

Ni

Mo

≤0.03

≤1.00

≤2.00

≤0.03

≤0.035

16.00-18.00

10.0-14.0

2.0-3.0





022CR17NI14MO2 Stainless Steel Heat Treatment:
 Annealing in the  temperature range of 1850 to 2050℃, then quickly annealing, and then rapidly cooling.316L stainless  steel cannot be overheat treated for hardening.

User Mode:

Annealed solid  solution state:
 NO.1,2B,N0.4,HL and so on surface states.
 022CR17NI12MO2 is  molybdenum stainless steel, as a result of molybdenum in steel, stainless  steel, the steel grade overall performance is better than 310 and 304, under  the condition of high temperature when the concentration of sulfuric acid is  less than 15% and higher than 85%, the 316L stainless steel has a wide range of  uses.




022Cr17Ni12Mo2  stainless steel also has good properties of chloride erosion, so it is usually  used in Marine environment.
 The maximum  carbon content of 022Cr17Ni12Mo2 stainless steel is 0.03, which can be used for  welding and can not be annealed and used for maximum corrosion resistance.



Welding
 022CR17NI12MO2  stainless steel has good welding performance. All standard welding methods can  be used for welding.




Welding can be  made according to the use of 316Cb, 316L or 309Cb stainless steel filler rod or  welding rod. In order to obtain the best corrosion resistance, the welding  section of 06Cr17Ni2Mo2 stainless steel needs to be annealed after welding. If  022Cr17Ni12Mo2 stainless steel is used, no post-welding annealing treatment is  required.


Product Description


022CR17NI14MO2 Stainless  Steel Characteristics:

  • Cold rolled product appearance  gloss, beautiful.

  • due to the addition of Mo,  corrosion resistance, especially excellent corrosion resistance.

  • excellent high temperature  strength.

  • excellent working hardening  (post-processing weak magnetism).

  • the solid solution state is not  magnetic.

  • compared with 304 stainless  steel, the price is on the high side.





Corrosion Resistance:
 Corrosion  resistance is superior to 304 stainless steel, and has good corrosion  resistance in pulp and paper production. And the 022Cr17Ni12Mo2 stainless steel  is also resistant to the erosion of the Marine and erosive industrial  atmosphere.

Heat Resistance:
 022CR17NI12MO stainless  steel has good oxidation resistance in discontinuous use below 1600 degrees and  in continuous use below 1700℃.



In the range of  800-1575 degrees, it is best not to continuously affect 022Cr17Ni12Mo2 stainless  steel, but the stainless steel has a good heat resistance when the 022Cr17Ni12Mo2  stainless steel is continuously used outside the temperature range.

The properties  of the carbonates of 022Cr17Ni12Mo2 rust steel are better than that of  06Cr17Ni2Mo2 stainless steel, which can be used in the above temperature range.



Product Application


022CR17NI12MO2 Stainless Steel Application:

  • Paper pulp and papermaking equipment heat exchangers

  • dyeing equipment

  • film washing equipment

  • pipes

  • coastal area building external materials.



Packaging and Delivery


  • Standard  exporting package.

  • Original  package or neutral package.

  • According  to clients’ needs.

  • Shipped  in 10-35 days after payment.



FAQ


Price
 Q: How can I get the price?
 A: You can contact us through sending inquiry, or get  price list by Email.

Delivery
 Q: How long is the delivery time?
 A: It depends on quantity. Usually, 10-35 working  days.

Sample
 Q: Can I get sample to check the quality?
 A: Of course. We can supply sample, and free for some  small value products.

OEM
 Q: Do you provide OEM service?
 A: Yes, we do. Customized design is available.

Payment
 Q: What is your payment term?
 A: L/C, T/T, Paypal, Western Union, etc.

Certificate
 Q: What certificate do your products have?
 A: CE, ISO9001, RoHS, SGS, etc.
