OEM: Available
Standard: ASME, ASTM, EN, UNS, GB, DIN, JIS
Product Certification: ISO, CE, RoHS
Payment Terms: T/T, L/C, PayPal, Western Union
Chemical Composition | |||||||||
Grade | Ni+Co | Cu | Si | Mn | C | Mg | S | Fe | Other |
≥ | ≤ | ||||||||
N2 | 99.98 | 0.001 | 0.003 | 0.002 | 0.005 | 0.003 | 0.001 | 0.007 | 0.02 |
N4 | 99.9 | 0.015 | 0.03 | 0.002 | 0.01 | 0.01 | 0.001 | 0.04 | 0.1 |
N6 | 99.6 | 0.06 | 0.1 | 0.05 | 0.1 | 0.1 | 0.005 | 0.1 | 0.5 |
N8 | 99 | 0.15 | 0.15 | 0.2 | 0.2 | 0.1 | 0.015 | 0.3 | 1 |
DN | 99.35 | 0.06 | .02-.10 | 0.05 | .02-.10 | .02-.10 | 0.005 | 0.1 | 0.35 |
NY1 | 99.7 | 0.1 | 0.1 | - | 0.02 | 0.1 | 0.005 | 0.1 | 0.3 |
NY2 | 99.4 | .01-.10 | 0.1 | - | - | - | .002-.01 | 0.1 | 0.6 |
NY3 | 99 | 0.15 | 0.2 | - | 0.1 | 0.1 | 0.005 | 0.25 | 1 |
NMg0.1 | 99.6 | 0.05 | 0.02 | 0.05 | 0.05 | .07-.15 | 0.005 | 0.07 | 0.4 |
NSi0.19 | 99.4 | 0.05 | .15-.25 | 0.05 | 0.1 | 0.05 | 0.005 | 0.07 | 0.5 |
Size(mm) | Tolerance(mm) | |||||
h8 | h9 | h10 | h11 | h12 | h13 | |
4.5≤Φ≤6.0 | 0/-0.018 | 0/-0.030 | 0/-0.048 | 0/-0.075 | 0/-0.120 | 0/-0.180 |
6.0≤Φ≤10 | 0/-0.022 | 0/-0.036 | 0/-0.058 | 0/-0.090 | 0/-0.150 | 0/-0.220 |
10≤Φ≤18 | 0/-0.027 | 0/-0.043 | 0/-0.070 | 0/-0.110 | 0/-0.180 | 0/-0.270 |
18≤Φ≤30 | 0/-0.033 | 0/-0.052 | 0/-0.084 | 0/-0.130 | 0/-0.210 | 0/-0.330 |
30≤Φ≤50 | 0/-0.039 | 0/-0.062 | 0/-0.100 | 0/-0.160 | 0/-0.250 | 0/-0.390 |
50≤Φ≤80 | 0/-0.046 | 0/-0.074 | 0/-0.120 | 0/-0.190 | 0/-0.300 | 0/-0.460 |
80≤Φ≤101.6 | 0/-0.054 | 0/-0.087 | 0/-0.140 | 0/-0.220 | 0/-0.350 | 0/-0.540 |
101.6≤Φ≤120 | 0/-0.220 | 0/-0.350 | 0/-0.540 | |||
120≤Φ | 0/-0.250 | 0/-0.400 | 0/-0.630 | |||
·Manufacture and handling of sodium hydroxide, particularly at temperature above 300C.
·Production of viscose rayon. Manufacture of soap.
·Analine hydrochloride production and in the chlorination of aliphatic hydrocarbons such as benzene, methane and ethane.
·Manufacture of vinyl chloride monomer.
·Reactors and vessels in which fluorine is generated and reacted with hydrocarbons.
1. Standard Exporting package.
2. Original package or neutral package.
3. According to clients ' needs.
4. Shipped in10-35 days after payment.
Price
Q: How can I get the price?
A: You can contact us through sending inquiry, calling, or get details price list by E-mail.
Delivery
Q: How long is the delivery time?
A: It depends on quantity. Usually, 10-35 working days.
Sample
Q: Can I get sample to check the quality?
A: Of course. We can supply sample, and free for some small value products.
OEM
Q: Do you provide OEM service?
A: Yes, we do. Customized design is available.
Payment
Q: What is your payment term?
A: L/C, T/T, PayPal, Western Union, etc.
Certificate
Q: What certificate do your products have?
A: CE, ISO9001, RoHS, SGS, etc.
Previous: Nickel 201
Next: No Information
