Characteristics: general corrosion resistance
Standard: ASME, ASTM, EN, UNS, GB, DIN, JIS
Certification: ISO, CE, ROHS
Payment Terms: T/T, L/C, Paypal, Western Union
434 Stainless Steel annealed sheet, chromium 12%~30%.Its corrosion resistance, toughness and weldability increase with the increase of chromium content. The corrosion resistance of chloride is better than that of other kinds of stainless steel. （18Cr-1Mo） is a modified steel of 430 steel, with a salt tolerance of 430 steel and used for automotive decoration materials.
>
434 Stainless Steel Chemical Composition | |||||||||
| Ni | Cr | Mn | Si | C | S | P | N | Fe |
min | 8.0 | 17.5 | -- | - | - | - | - | - | - |
max | 10.5 | 19.5 | ≤2.0 | ≤1.0 | ≤0.0025 | ≤0.03 | 0.045 | ≤0.10 | Balance |
Physical Performance | |||
Density | Melting Point | Poisson’s ratio | Specific resistance |
7.93 g•cm-3 | 1398~1420℃ | 0.3 | 0.73 Ω•mm2•m-1/ft |
Temperature, °F | 70 | 212 | 932 |
Coefficient of thermal expansion, in/in°F*10-6 | - | 9.2 | - |
Heat conductivity | - | 9.4 | 12.4 |
Elasticity modulus | 29 | - | - |
*70°F to indicated temperature.
434 Stainless Steel Characteristics:
Good general corrosion resistance.
Easy to clean up.
Excellent strength and toughness at low temperature.
Good forming performance.
Good welding property
Typical tensile property
Largest strength of extension, ksi | 75 |
0.2%yield strength, ksi | 30 |
Ductility,% | 40 |
HB,Brinell | 201 |
Typical tensile and impact properties
Temperature, °F | -425 | -320 | -100 | 70 | 400 | 800 | 1200 |
Largest strength of extension, ksi | 250 | 230 | 150 | 90 | 70 | 66 | 48 |
0.2%yield strength, ksi | 100 | 70 | 50 | 35 | 23 | 19 | 15.5 |
Charpy impact V notch,ft-lbs | 85 | 85 | - | 150 | - | - | - |
434 Stainless Steel application:
Food processing and processing.
Heat exchanger.
Pressure vessels for the chemical industry.
Conveyer.
Architecture.
Standard exporting package.
Original package or neutral package.
According to clients’ needs.
Shipped in 10-35 days after payment.
Spot delivery, including delivering small batches of goods
Provide wide-range and complete materials series products
Cutting plates, including complex shapes of materials and special processing and disposal
Cutting bars and strips
Our application technology expert provide the best material and recommendation
One-stop service
