Nimonic 93

Characteristic: Good combination property
Standard: ASME, ASTM, EN, UNS, GB, DIN, JIS
Certification: ISO, CE, ROHS
Payment Terms: T/T, L/C, Paypal, Western Union

Send Inquiry

Product Details

Nimonic 93 is  contained more precipitation hardening of cobalt and chromium nickel base  alloy, has high strength and good stability, use it under 815 ℃, good comprehensive performance. Turbine  blades for aero engines, small engine turbine disks and fasteners. The alloy  has good thermal plasticity and can be supplied with sheet, rod and forgings.




Nimonic 93

Chemical Composition

C

Cr

Ni

Co

Al

Ti

Fe

B

≤0.13

18.0~21.0

remainder

15.0~21.0

1.0~2.0

2.0~3.0

≤1.00

≤0.02

Mn

Si

P

S

Cu

Pb

Ce、Zr、Mg

≤1.00

≤1.00

≤0.015

≤0.015

≤0.20

≤0.0025

trace



Nimonic 93 Thermal Properties



θ/℃

20

100

200

300

400

500

600

700

800

900

1000

λ/(W/(m·C))

11.47

12.77

14.44

15.99

17.54

18.97

20.64

22.32

23.99

25.83

27.88





Specific Heat

θ/℃

20

100

200

300

400

500

600

700

800

900

1000

c/(J/(kg.℃))

446

467

494

520

547

572

600

626

652

679

706



Coefficient of Linear Expansion

θ/℃

16~100

16~200

16~300

16~400

16~500

16~600

16~700

α/10-6C-1

11.91

12.97

13.52

14.10

14.49

14.99

15.61



Chemical Performance

θ/℃

700

800

900

Oxidation rate(g/(m3·h))

0.0398

0.0236

0.1435



Product Description


Nimonic 93 heat treating regime 1050~1080℃, 8h, air cooling+710℃±10℃,16h air cooling.
 Nimonic 93 specifications and supply state  can supply d20 ~ 22 mm hot rolled bars, the delta 0.4 ~ 4 mm plate, d120mm  following forgings and forging materials, plank to solid solution state  delivery, other varieties are forging and rolling state delivery.
 Nimonic93 smelting and casting process  vacuum induction melting + vacuum arc or electroslag remelting process.
 The Nimonic93 application profile and  special requirements for the alloy made of aero-engine parts are adopted in the  UK and France, and are used in domestic manufacturing of free turbines,  gaskets, gaskets, locking plates and so on.
 Nimonic93 corrosion-resistant alloy has  good corrosion resistance.





Product Application




 Product Show




Our Service


  • Spot delivery, including delivering small batches of goods

  • Provide wide-range and complete materials series products

  • Cutting plates, including complex shapes of materials and special  processing and disposal

  • Cutting bars and strips

  • Our application technology expert provide the best material and  recommendation

  • One-stop service
